Acoustic Door Finder
| STC Rating | Fire Rating | Swing | Max Opening/Size | Lite Opening | Perimeter Gaskets | Bottom Seal/Sweep | Threshold | Astragal | Weight lbs/ft² | Mfg Site Restrictions |
|---|---|---|---|---|---|---|---|---|---|---|
| 30 | 20 | Single | 4x10 | Flush - No Lite Cutout | 2 | e | N/R | N/A | 5.5 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 20 | Single | 4x10 | Metal Vision Frame; Up-to 1290 sq. in. visible glass; 30" max width, 43" max length with 1/4" Pyroswiss Or Wirelite NT Or Fireglass20 Glass | 2 | e | N/R | N/A | 5.5 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 45 | Single | 4x10 | Flush - No Lite Cutout | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 45 | Single | 4x10 | Metal Vision Frame; Up-to 1290 sq. in. visible glass; 30" max width, 43" max length; with 1/4" Wirelite NT Or 3/16" Firelite NT Or 5/16" Firelite Plus Or 5/16" Keralite FR-L Glass | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 60 | Single | 4x10 | Flush - No Lite Cutout | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 60 | Single | 4x10 | Metal Vision Frame; Up-to 1290 sq. in. visible glass; 30" max width, 43" max length; with 1/4" Wirelite NT Or 3/16" Firelite NT Or 5/16" Firelite Plus Or 5/16" Keralite FR-L Glass | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 90 | Single | 4x10 | Flush - No Lite Cutout | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | 90 | Single | 4x10 | Metal Vision Frame; Up-to 1290 sq. in. visible glass; 30" max width, 43" max length; with 1/4" Wirelite NT Or 3/16" Firelite NT Or 5/16" Firelite Plus Or 5/16" Keralite FR-L Glass | 2 | e | N/R | N/A | 3.7 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | NR | Single | 4x10 | Flush - No Lite Cutout | 2 | e | N/R | N/A | 5.5 | Mason City, Jefferson City, Marshfield, Northumberland |
| 30 | NR | Single | 4x10 | Metal Vision Frame; Up-to 1290 sq. in. visible glass; 30" max width, 43" max length with 1/4" Tempered Glass | 2 | e | N/R | N/A | 5.5 | Mason City, Jefferson City, Marshfield, Northumberland |
Gaskets | Drop Seals or Sweep | Thresholds | |||||
1 | S773 double row, S44 single row | N/R | Not Required | N/R | Not Required | ||
2 | S88 double row | a | Zero 360 | i | Pemko 2008STCxQ380 | ||
3 | HSS2000* | b | Pemko 211 Door Shoe | ii | Gasketed ADA approved Threshold for Sound | ||
4 | S88 single, S773 single, P112 Corner Pads | c | NGP 225N | iii | NGP 896S | ||
5 | 2 ACP 112 corner pad | d | Pemko 234 Door Shoe | iv | NGP 8144 | ||
6 | S773 single row, S44 single row | e | Zero 369 | ||||
7 | Zero 119WB and 8145 Head & Jamb perimeter seals | f | Pemko 411 | ||||
8 | S773 one row, 2-P112 corner pads | g | Pemko 3692APK773 | ||||
9 | NGP 5075B, 5060B, 60FP corner pads | h | NGP 225SxSTC 2 | ||||
12 | S88 two rows | k | NGP12T6xSTC-FH |
Notes:
*** STC construction only, not evaluated for STC rating with lite opening.
* Additional requirement for fire rating
Ŧ Anemostat LoPro frame required. Maximum visible glass size-24” x 52” with Firelite NT 5/16”glass. Maximum lite size of 1188 sq. in. Factory glazing required Lite openings exceeding 100 sq. in. or those exceeding 12” in width or 33” in length will not carry a Temperature Rise label
Non acoustic labeled construction available at Saint-Éphrem, upon request.
